Product Detail

installed Long Arm Lift Kit and oversized tires, the highly detailed truck body stands over an inch taller than the standard TRX-4 Sport chassis for legendary off-road capability and performance on the trail. To further the appearance, this truck uses the Traxxas Clipless Body Mounting for added scale realism!

The TRX-4 sport High Trail Edition is the perfect vehicle for the driver who wants it all; extreme all-terrain capability, stunning scale looks, and unmatched durability! This High Trail Edition TRX-4 Sport uses portal axles, 110mm threaded shocks, oversized Canyon Trail tires mounted to 2.2' wheels and a lift kit giving you extreme ground clearance and a boost in capability and performance to conquer the toughest terrains!

Features

• Molded Scale Detail: The Body comes with authentic-looking expedition roof rack, snorkel, side mirrors, traction boards, fire extinguisher, jack, and fuel canisters.
  Clip-less Body Mounting System: Traditional posts and body clips are gone, and instead an integrated quick-release system secures the body invisibly. The hidden mechanism holds tight on the trail yet releases in just seconds to access the chassis.

• Trail-tuned XL-5 HV Waterproof Electronic Speed Control: HV electronic speed control brings 3s LiPo capability for strong efficient running. The powerful 21T Titan motor provides torque for hauling heavy loads and climbing steep grades.

• Factory-Installed Long Arm Lift Kit: The lift kit not only gives you an extra inch of ground clearance but also maintains the TRX-4's suspension geometry.
  Standard 312mm Wheelbase: The 312mm wheelbase makes the truck compatible with many after market scale and performance parts.

• The Power of Portals: The portal axles work in tandem with the Lift Kit to lift the truck for huge center ground clearance. The portal axles’ internal gear reduction virtually eliminates torque twist, keeping the truck straight and on course.

• Extended Aluminum GTS Shocks: These shocks are 20mm longer than the standard GTS shocks. The threaded shock bodies are silver-anodized to deliver silky-smooth dampening.

• Oversize Wheels and Tires: The aggressive Canyon Trail tires feature large lugs for increased grip with foam inserts for realistic trail performance. Slotted chrome
• Mag wheels come with replica locking hubs to conceal the wheel nuts.
  Sealed Ball Bearings: Reliable sealed ball bearings are used throughout the chassis for long-lasting performance.

Specifications

• Scale: 1/10

• Length: 22' (564mm)

• Track Width (Front/Rear): 10.60' (270mm)

• Center Ground Clearance: 4' (99mm)

• Height (Overall): 10.8' (275mm)

• Wheelbase: 12.3' (312mm)

• Weight (w/o Battery): 7.04lbs (3.20kg)

• Shock Length (Front/Rear): 4.33' (110mm)

• Wheels (Front/Rear): 2.2x1.34' (56x34mm)

• Tires (Front/Rear): 5.3x2.14' (135x54mm)

• Approach Angle: 62.8°

• Departure Angle: 54.7°

• Breakover Angle: 79.3°

• Hex Size: 12mm

• Gear Pitch: 32P

• Battery Tray Size (LxWxH): 158.75x47x23/26mm

Includes

• (1) Traxxas TRX-4 Sport 1/10 High Trail Edition RC Crawler

• (1) TQi 2.4 GHz 3-Channel Transmitter

• Maintenance Tools

Needed to Complete

• (4) 'AA' Batteries (for transmitter)

• (1) NiMH Battery (4-7 cell) or LiPo Battery (2S/3S)

• (1) Compatible Battery Charger
